Photoelectric Sensor, Diffuse Mode Sensor with Adjustable Background Suppression, Operating voltage 10…30 VDC, Max. range 1000 mm, Cable length 0.15 m, Cable with male end M12 × 1, 5-pin, PUR, 150 mm, Protection class IP67, 5-segement LED display, Signal indication, Keylock, Switch ON/OFF delay, adjustable between 8…16 ms, Operating voltage: 10…30 VDC, Switching output, bipolar, Light or dark operation
- SKU0662488719593
- Manufacturer code3071959
- Type of electric connectionConnector M12
- Type of switching outputPNP/NPN
- Type of switch functionNormally open contact (NO)
- Construction type housingCuboid
- Width sensor25 mm
- Height of sensor75 mm
- Length of sensor60 mm
- Sensing modeLight switching
Dark switching - Material of optical surfacePlastic
- Ambient temperature-20 - 55 °C
- Response time2 s
- Switching frequency250 Hz
- Wavelength of the sensor665 nm
- Type of lightPolarity free red light
- Suitable for safety functionsfalse
- Degree of protection (IP)IP67
- Material of cable sheathPolyurethane (PUR)
- Rated switching distance1000 mm
- Max. switching distance1000 mm
- Adjustment range200 - 1000 mm
- Housing materialPlastic
- Type of switching outputPNP/NPN
- Connector gendermale
- Cable length (m)0.15
This product is unavailable
This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
- Manufacturer Turck
