QM42VP6AF150 Photoelectric Sensor, Diffuse Mode Sensor with Fixed-Field Background Suppressio
Manufacturer: Turck Code: 3045688 SKU: 0662488456887
Photoelectric Sensor, Diffuse Mode Sensor with Fixed-Field Background Suppression, Operating voltage 10…30 VDC, Max. range 150 mm, Cable length 2 m, Cable, PVC, 2 m, 4-wire, Metal housing, ZN, black, Protection class IP67, Scanning width adjusted via potentiometer, Operating voltage 10…30 VDC, PNP switching output, Light/dark operation
- SKU0662488486952
- Manufacturer code3048695
- Type of electric connectionCable
- Type of switching outputPNP
- Type of switch functionChangeover contact (NO/NC)
- Construction type housingCuboid
- Width sensor12.7 mm
- Height of sensor42 mm
- Length of sensor42 mm
- Sensing modeLight-/dark switching
- Material of optical surfacePlastic
- Ambient temperature-20 - 55 °C
- Response time1 s
- Switching frequency500 Hz
- Wavelength of the sensor680 nm
- Type of lightPolarity free red light
- Suitable for safety functionsfalse
- Degree of protection (IP)IP67
- Material of cable sheathPolyvinyl chloride (PVC)
- Rated switching distance150 mm
- Max. switching distance150 mm
- Adjustment range50 - 150 mm
- Housing materialMetal
- Type of switching outputPNP
- Cable length (m)2
This product is unavailable
This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
- Manufacturer Turck
Product attachments
file-39691-8c92ebbf679ac322c8a269bb08fc714b.pdf (PDF, 457.8 kB)Related products
