ODS9L2.8/L6X-650-M12 Sensors for distance measurement with high precision

ODS9L2.8/L6X-650-M12
High-precision sensors for distance measurement using laser technology.
  • SKU
    2110-50137821
  • Manufacturer code
    50137821
  • Operational controls
    Push button
  • Type of analogy output
    Other
  • Type of electric connection
    Connector M12
  • Type of switching output
    PNP/NPN
  • Type of switch function
    Anticoincidence
  • Operation agent-safety class
    Safety class 3
  • Supply voltage
    18 - 30 V
  • Width sensor
    21 mm
  • Height of sensor
    50 mm
  • Length of sensor
    50 mm
  • Setting procedure
    Manual adjustment
  • Explosion safety category for gas
    None
  • Explosion safety category for dust
    None
  • Construction type housing
    Cuboid
  • Laser protection class
    Class 2
  • Type of light
    Laser diode, red light
  • Relative linearity deflection
    1 %
  • Measuring principle for optical distance measurement
    Triangulation
  • Degree of protection (IP)
    IP67
  • Voltage type
    DC
    DC
    DC
    DC
  • Ambient temperature
    -20 - 50 °C
  • Pre failure notice
    false
  • Material of optical surface
    Glass
  • Housing material
    Plastic
  • Material of cable sheath
    Other
  • With time function
    false
  • Relative measurement accuracy
    0 %
  • Sensing mode
    Light-/dark switching
  • Supplyoltage (V)
    18 ... 30
  • Operational controls
    PC software
    Control buttons
  • Scanning system
    Against object
  • Measuring range
    50 ... 650
  • Interface
    IO-Link
  • Manufacturer Leuze

Product attachments

DS_ODS9L2-8-L6X-650-M12_eng_50137821 (LINK)
