BI7-Q08-LIU Inductive Sensor, With Analog Output

BI7-Q08-LIU

Inductive Sensor, With Analog Output, Operating voltage 15…30 VDC, Measuring range 1 mm - 4 mm, Flush, Cable length 2 m, Rectangular, height 8 mm, Active face on top, Metal, Zamak, nickel-plated, 4‐wire, 15…30 VDC, Analog output, 0…10 V and 0…20 mA, Cable connection

  • SKU
    4047101145861
  • Manufacturer code
    1534605
  • Operating voltage
    15 - 30 V
  • Supply voltage
    15 - 30 V
  • Limiting frequency
    200 Hz
  • Relative linearity deflection
    5 %
  • Measuring range
    1 - 4 mm
  • Type of electric connection
    Cable
  • Type of analogy output
    0 V ... 10 V
  • Mechanical mounting condition for sensor
    Concise
  • Housing material
    Other
  • Material active area of sensor
    Plastic
  • Material of cable sheath
    Polyurethane (PUR)
  • Construction type housing
    Cuboid
  • Length of sensor
    32 mm
  • Ambient temperature
    -25 - 70 °C
  • Degree of protection (IP)
    IP68
  • Width sensor
    20 mm
  • Height of sensor
    8 mm
  • Flush / Non-flush
    Flush
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-37777-992ffe8f2888dda8f1bd15fa3fd5a8c8.pdf (PDF, 1023.73 kB)
