DT3001-U4-A-C3 Eddy current measuring system

DT3001-U4-A-C3
The eddyNCDT 3001 is used for non-contact distance, proximity, and position measurement in machine and process monitoring. It is particularly resistant to pressure, oil, dirt, and temperature, and is often used as a replacement for inductive displacement sensors and switches.
  • SKU
    7965-4314002.03
  • Manufacturer code
    4314002.03
  • Measuring range
    4 mm
  • Type of electric connection
    integrated cable, 5-pin, lenght 3 m
  • Protection class
    IP67
  • Supply voltage
    24 V (11 ... 30 V)
  • Target material
    Aluminium (non-ferromagnetic targets)
  • Frequency response (-3dB)
    5 kHz
  • Temperature compensation up to
    70°C

Product attachments

file-1129-b8b8b02c72c70ce78f2b3bbfdcc45086.pdf (PDF, 360.29 kB)
