SLPMP14-1390 Safety Light Curtain, Emitter/Receiver Pair, Integrated Muting Function

SLPMP14-1390

Safety Light Curtain, Emitter/Receiver Pair, Integrated Muting Function, Operating voltage 20…28 VDC, Max. range 7000 mm, Electrical connection via RDLP‐8 with open end or via DELPE‐8 with male M12 x 1, 8‐pin, Protection class IP65, Flat housing without blind zone, Adjustments via DIP switch, Resolution can be reduced, Blanking function, Operating voltage: 24 VDC ± 15 %, Resolution 14 mm, Scan field 1390 mm (L1), Mounting bracket included in delivery

  • SKU
    0662488844936
  • Manufacturer code
    3084493
  • Fade-out possible
    true
  • Type of switching output of the OSSD
    PNP
  • With muting function
    true
  • Resolution of the light curtain
    14 mm
  • Protective field height (mm)
    1390 mm
  • With restart blockage
    true
  • Suitable for safety functions
    true
  • Type of electric connection
    Flat plug-in connection
  • Height of sensor
    1388 mm
  • Ambient temperature
    0 - 55 °C
  • Wavelength of the sensor
    850 nm
  • Number of protected semiconductor outputs
    2
  • Max. output current at protected output
    500 mA
  • Width sensor
    28 mm
  • Length of sensor
    26 mm
  • Response time
    34.5 s
  • Connector gender
    male

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-37076-67da172c854ae682c18a6b2ffc78826b.pdf (PDF, 142.08 kB)
