KD 01-5-SA Connector

KD 01-5-SA
M12 axial male connector, A-coded, 5-pin.
  • SKU
    2110-50040098
  • Manufacturer code
    50040098
  • Rated current In
    4 A
  • Ambient temperature
    -40 - 85 °C
  • Screened
    no
  • Material of contact surface
    Other
  • Contact type
    Pin
  • Number of data contacts
    0
  • Number of control contacts
    0
  • Positioning
    Straight
  • Type of electric connection
    Screw connection
  • Housing material
    Other
  • Coating housing
    None
  • Type of locking
    Gland nut
  • Degree of protection (IP), mounted
    IP67
  • With status indication
    false
  • For cable outer diameter
    6 - 8 mm
  • Material thread ring
    Zinc die-cast
  • Connectable conductor cross section fine-strand with cable end sleeve
    18 - 18 mm²
  • Connectable conductor cross section solid-core
    18 - 18 mm²
  • Rated voltage
    60
  • Manufacturer Leuze

Product attachments

DS_KD-01-5-SA_eng_50040098 (LINK)
