RSCV4T-5/TFW Actuator And Sensor Cable, PP-EPDM, Connection Cable

RSCV4T-5/TFW

Actuator And Sensor Cable, PP-EPDM, Connection Cable, Voltage 250 V, Cable length 5 m, M12 male connector, straight, 3-pin, Stainless steel coupling nut/screw, Sheath material: PP-EPDM, Sheath color: white, Resistant to acids and alkaline solutions, Resistant to detergents and disinfectants, Resistant to hydrolysis acc. to DIN EN 60068-2-78, Free from silicone and PVC, Halogen-free acc. to DIN EN 50267-2-1, IEC 60754-1, VDE 0482-267-2-1, Approvals: Ecolab, FDA, RoHS and REACH compliant, Protection classes IP67, IP69K, Cable length: 5.0 m

  • SKU
    4047101388855
  • Manufacturer code
    6935399
  • Number of poles
    3
  • Jacket color
    White
  • Material contact body
    CuZn
  • Permitted cable outer temperature after assembling without vibration
    -40 - 105 °C
  • Rated current In
    4 A
  • Rated voltage
    250 V
  • Gender, box-sided
    Male (plug)
  • Positioning, box-sided
    Straight
  • Permitted cable outer temperature during assembling/handling
    0 - 80 °C
  • Screened
    false
  • Jacket material
    Other
  • With LED indication
    false
  • Type of electric connection, box-sided
    M12
  • Material of contact surface
    Gold
  • Connector gender
    male
  • Cable length
    5 m
  • Approvals / Compliance
    Ecolab
    FDA
    RoHS
    REACH
  • Cable length (m)
    5
  • Manufacturer Turck

Product attachments

file-40235-bcfdeae71efd6fe7c659f6e4e4dc4217.pdf (PDF, 187.58 kB)
