Aluminium enlosure
Protection class IP65

SKU

4030661463469
Manufacturer code

101198091
Coding, Key number

102
Housing color

Red
Colour of the key

Silver
Colour, key head

Silver
Type of Execution, IP Protection class, General

IP65
Type of Execution, Mechanical life, minimum,

100000 Operations
Housing material

Aluminium / chromated steel
Standard, standards

EN IEC 60947-5-1
PIM maintenance status

Discharge "Online catalog"
Temperature, Ambient temperature[generated product variant]

-25 ... +70 °C
Temperature, ambient temperature, maximum

70 °C
Temperature, ambient temperature, minimum

-25 °C
Web Type

Product range
PNV, standard, certificates

TÜV
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661463469
SAP, product group

Initial
SAP, gross weight

450.000 g
SAP, net weight

450.000 g
Selection (Yes/No), Traceparts

Yes
Height, General

103 mm
Length, General

90 mm
Width, General

40 mm
Clamping force

1750 N
Latching force

5 N
Material, cylinder lock

Steel
Material, enclosure coating

painted
Note, applications

sliding safety guard
removable guard
hinged safety guard
Number, Actuating directions

4
Number, Keys

1
Review, restistance to shock

30 g / 18 ms
Temperature, storage and transport temperature,[generated product variant]

-40 ... +80 °C
Temperature, storage and transport temperature, maximum

80 °C
Temperature, storage and transport temperature, minimum

-40 °C
