1 Cable entry M 20 x 1.5
LED version available
Metal enclosure
Good resistance to oil and petroleum spirit
Actuator heads can be repositioned by 4 x 90°
40,5 mm x 107 mm x 65,3 mm
Actuator shaft can be turned 360°

SKU

4030661188874
Manufacturer code

101160104
CAD, traceparts, product ID

33-22052019-077556
Current, Thermal test current

10 A
Current, Utilisation category AC-15

4 A
Current, Utilisation category DC-13

4 A
Type of Execution, IP Protection class, General

IP67
Type of Execution, Mechanical life, minimum,

1000000 Operations
Switching principle

Slow action
Angle, Positive break angle

7 °
Height, Sensor

107 mm
Length, Sensor

65.3 mm
Width, Sensor

40.5 mm
Electrical data, Cable section, maximum

2.5 mm²
Electrical data, Cable section, minimum

0.75 mm²
Electrical data, Max. fuse rating

6 A gG D-fuse
Electrical data, Utilisation category

DC-13
AC-15
Material, contacts, electrical

Silver
Housing material

Light alloy die-casting
Note, Electrical Data, Cable section

All indications including the conductor ferrules.
Note, General

By turning the head in 90° steps, 8 actuating planes are pos
Adjustment tool: locking screw to fix, shaft pre-drilled to
Universal joint available to compensate for axial displaceme
Number, Safety contacts

1
PIM maintenance status

Discharge "Online catalog"
PNV, standard, certificates

CCC
cULus
Type of switch function

NO contact, NC contact
Type of electric connection

Screw terminals M20 x 1.5
Safety parameters, Mission time

20 Year(s)
Safety parameter

EN ISO 13849-1
EN IEC 60947-5-1
BG-GS-ET-15
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661188874
SAP, product group

Initial
SAP, gross weight

260.000 g
SAP, net weight

260.000 g
Temperature, Ambient temperature[generated product variant]

-25 ... +70 °C
Temperature, ambient temperature, maximum

70 °C
Temperature, ambient temperature, minimum

-25 °C
Time, Switching frequency

1000 /h
Voltage, Rated impulse withstand voltage

6 kV
Voltage, rated insulation voltage

500 V
Voltage, Utilisation category AC-15

230 VAC
Voltage, Utilisation category DC-13

24 VDC
Web Type

Product range
Number, Auxiliary contacts

1
Type of execution, Actuating element

Other
Type of Execution, Connector enclosure, Side B

Female connector
Mounting hole, Shaft

10 mm
Material, enclosure coating

painted
Tightening torque, Positive break torque

0.60 Nm
