2 cable entries M20
Cast iron enclosure, 2K paint
Exterior parts made of stainless steel
2 switching angles (prewarning, deactivation)

SKU

4030661490779
Manufacturer code

103013113
Current, Thermal test current

10 A
Current, Utilisation category AC-15

4 A
Type of Execution, IP Protection class, General

IP66
IP67
Type of Execution, Mechanical life, minimum,

1000000 Operations
Switching principle

Slow action
Height, Sensor

153 mm
Length, Sensor

64 mm
Width, Sensor

118 mm
Electrical data, Cable section, maximum

2.5 mm²
Electrical data, Cable section, minimum

0.75 mm²
Electrical data, Max. fuse rating

6 A gG D-fuse
Electrical data, Utilisation category

AC-15
DC-13
Material, contacts, electrical

Silver
Housing material

Cast iron
Material, enclosure coating

2K paint
Standard, standards

EN IEC 60947-5-1
Number, NC contacts

2
Number, NO contacts

2
PIM maintenance status

Discharge "Online catalog"
PNV, standard, certificates

CCC
cULus
Type of switch function

NO contact, NC contact
Type of electric connection

Screw terminals M20 x 1.5
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661490779
SAP, product group

Initial
SAP, gross weight

1895.000 g
SAP, net weight

1895.000 g
Temperature, Ambient temperature[generated product variant]

-40 ... +70 °C
Temperature, ambient temperature, maximum

70 °C
Temperature, ambient temperature, minimum

-40 °C
Voltage, Rated impulse withstand voltage

6 kV
Voltage, rated insulation voltage

500 V
Voltage, Utilisation category AC-15

230 VAC
Web Type

Product range
Type of application, Actuating direction

each time 60° right-hand side and left-hand side rotation
Current, Utilisation category DC-13

1 A
Voltage, Utilisation category DC-13

24 VDC
