KG3-07A31 60 Contactor relay 3NO+1NC, Coil 60V= DC, Coil power consumption 3W

KG3-07A31 60

Contactor relay 3NO+1NC, Coil 60V= DC, Coil power consumption 3W inrush/sealed, ambient temperature rating from -40°C till +90°C

  • SKU
    9005738971111
  • Manufacturer code
    KG3-07A31 60
  • Rated control supply voltage Us at AC 50HZ
    0 - 0 V
  • Rated control supply voltage Us at AC 60HZ
    0 - 0 V
  • Rated control supply voltage Us at DC
    60 - 60 V
  • Voltage type for actuating
    DC
  • Rated operation current Ie , 400 V
    2 A
  • Connection type auxiliary circuit
    Screw connection
  • Mounting method
    DIN-rail/screw
  • Interface
    false
  • Number of auxiliary contacts as normally closed contact
    1
  • Number of auxiliary contacts as normally open contact
    3
  • Number of auxiliary contacts as normally closed contact, delayed switching
    0
  • Number of auxiliary contacts as normally open contact, leading
    0
  • With LED indication
    false
  • Number of auxiliary contacts as change-over contact
    1
  • Manual operation possible
    false
