R40-30 230 Modular contactor LOW NOISE 40A 3NO, Coil 230VAC 50Hz

R40-30 230

Installation contactor for distribution board LOW NOISE 40A 3-pole 3NO, Coil 220-240V 50Hz 230-264V 60Hz, maximum switchable lamp loads!

  • SKU
    9005738887405
  • Manufacturer code
    R40-30 230
  • Degree of protection (IP)
    IP40
  • Rated operating voltage
    440 - 440 V
  • Rated operation current
    40 A
  • Utility category
    1
  • Rated excitation voltage
    220 - 240 V
  • Voltage type (operating voltage)
    AC
  • Voltage type (excitation voltage)
    AC
  • Number, NO contacts
    3
  • Number, NC contacts
    0
  • Max. incandescent lamp load
    6000 W
  • Max. load fluorescent lamp
    2975 VA
  • Max. load fluorescent lamp (Duo circuit)
    5280 VA
  • Max. load fluorescent lamp (parallel compensated)
    2805 VA
  • Slider for hand switch
    false
  • Number of modular spacings
    3
  • Built-in depth
    60 mm
  • Additional equipment possible
    true
