K3-32A00 230 Contactor 15kW/AC3, 3-pole, Coil 230VAC 50Hz

K3-32A00 230

Contactor 15kW/AC3/400V 3-pole, Coil 220-240V 50Hz 240V 60Hz, ambient temperature rating from -40°C till +90°C, smallest sizes at maximum performance!

  • SKU
    9005738816719
  • Manufacturer code
    K3-32A00 230
  • Rated control supply voltage Us at AC 50HZ
    220 - 240 V
  • Rated control supply voltage Us at AC 60HZ
    230 - 264 V
  • Rated control supply voltage Us at DC
    0 - 0 V
  • Voltage type for actuating
    AC
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Rated operation current Ie at AC-1, 400 V
    65 A
  • Rated operation current Ie at AC-3, 400 V
    32 A
  • Rated operation power at AC-3, 400 V
    15 kW
  • Rated operation current Ie at AC-4, 400 V
    32 A
  • Rated operation power Ie at AC-4, 400 V
    15 kW
  • Modular version
    true
  • Type of electrical connection of main circuit
    Screw connection
  • Number of normally closed contacts as main contact
    0
  • Number of main contacts as normally open contact
    3
