K3-176A00 180 Contactor 90kW/AC3, 3-pole, Coil 180VAC/180=VDC

K3-176A00 180

Contactor 90kW/AC3/400V 3-pole, Coil 180-200V 50/60Hz 180V= DC

  • SKU
    9005738218025
  • Manufacturer code
    K3-176A00 180
  • Rated control supply voltage Us at AC 50HZ
    180 - 200 V
  • Rated control supply voltage Us at AC 60HZ
    180 - 200 V
  • Rated control supply voltage Us at DC
    180 - 180 V
  • Voltage type for actuating
    AC/DC
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Rated operation current Ie at AC-1, 400 V
    250 A
  • Rated operation current Ie at AC-3, 400 V
    175 A
  • Rated operation power at AC-3, 400 V
    90 kW
  • Rated operation current Ie at AC-4, 400 V
    63 A
  • Rated operation power Ie at AC-4, 400 V
    30 kW
  • Modular version
    false
  • Type of electrical connection of main circuit
    Cable clamp
  • Number of normally closed contacts as main contact
    0
  • Number of main contacts as normally open contact
    3
