K2-45A00-40 400 Contactor 22kW/AC3, 4-pole, Coil 400VAC 50Hz

K2-45A00-40 400

Contactor 22kW/AC3/400V 4-pole, Coil 380-415V 50Hz 415-440V 60Hz, ambient temperature rating from -40°C till +90°C

  • SKU
    9005738634016
  • Manufacturer code
    K2-45A00-40 400
  • Rated control supply voltage Us at AC 50HZ
    380 - 415 V
  • Rated control supply voltage Us at AC 60HZ
    400 - 460 V
  • Rated control supply voltage Us at DC
    0 - 0 V
  • Voltage type for actuating
    AC
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Rated operation current Ie at AC-1, 400 V
    80 A
  • Rated operation current Ie at AC-3, 400 V
    45 A
  • Rated operation power at AC-3, 400 V
    22 kW
  • Rated operation current Ie at AC-4, 400 V
    45 A
  • Rated operation power Ie at AC-4, 400 V
    22 kW
  • Modular version
    true
  • Type of electrical connection of main circuit
    Screw connection
  • Number of normally closed contacts as main contact
    0
  • Number of main contacts as normally open contact
    4
