K1-07L22= 24 Mini contactor relay solder pins 2NO+2NC, Coil 24V= DC

K1-07L22= 24

Mini contactor relay solder pins 2NO+2NC, Coil 24V= DC, selfcleaning doublecontacts suitable for electronic circuits - 17VDC, 5mA, ambient temperature rating from -40°C till +90°C, smallest sizes at maximum performance!

  • SKU
    9005738044815
  • Manufacturer code
    K1-07L22= 24
  • Mounting method
    PCB
  • Rated control supply voltage Us at AC 50HZ
    0 - 0 V
  • Rated control supply voltage Us at AC 60HZ
    0 - 0 V
  • Rated control supply voltage Us at DC
    24 - 24 V
  • Voltage type for actuating
    DC
  • Rated operation current Ie , 400 V
    2 A
  • Connection type auxiliary circuit
    Soldering connection
  • Interface
    false
  • Number of auxiliary contacts as normally closed contact
    2
  • Number of auxiliary contacts as normally open contact
    2
  • Number of auxiliary contacts as normally closed contact, delayed switching
    0
  • Number of auxiliary contacts as normally open contact, leading
    0
  • With LED indication
    false
  • Number of auxiliary contacts as change-over contact
    2
  • Manual operation possible
    true
