K1-12D00-22 42 Mini contactor 5,5kW/AC3, 4-pole 2NO + 2NC, Coil 42VAC 50Hz

K1-12D00-22 42

Mini contactor 5,5kW/AC3/400V 4-pole 2NO + 2NC, Coil 42V 50/60Hz, ambient temperature rating from -40°C till +90°C, smallest sizes at maximum performance!

  • SKU
    9005738783370
  • Manufacturer code
    K1-12D00-22 42
  • Rated control supply voltage Us at AC 50HZ
    38.5 - 42 V
  • Rated control supply voltage Us at AC 60HZ
    42 - 42 V
  • Rated control supply voltage Us at DC
    0 - 0 V
  • Voltage type for actuating
    AC
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Rated operation current Ie at AC-1, 400 V
    20 A
  • Rated operation current Ie at AC-3, 400 V
    12 A
  • Rated operation power at AC-3, 400 V
    5.5 kW
  • Rated operation current Ie at AC-4, 400 V
    12 A
  • Rated operation power Ie at AC-4, 400 V
    5.5 kW
  • Modular version
    true
  • Type of electrical connection of main circuit
    Screw connection
  • Number of normally closed contacts as main contact
    2
  • Number of main contacts as normally open contact
    2
