SKU4030661519487
-
Manufacturer code103027025
-
Type of Execution, construction formWith integrated LED
-
Type of executionLED module
-
Standard, standardsEN IEC 60947-5-1
EN IEC 60947-1 -
PIM maintenance statusDischarge "Online catalog"
-
SAP, basic quantity unitPiece
-
SAP, EAN (European Article Number)4030661519487
-
SAP, product groupInitial
-
SAP, gross weight23.000 g
-
SAP, net weight23.000 g
-
Temperature, Ambient temperature[generated product variant]-25 ... +75 °C
-
Temperature, ambient temperature, maximum75 °C
-
Temperature, ambient temperature, minimum-25 °C
-
Web TypeProduct range
-
Type of Execution, Terminals, mechanicalarbitrarily
-
Selection (Yes/No), Integral System Diagnostics, generalYes
-
Type of application, Installation instructionspluggable
-
Type of Execution, IP Protection class, clips or terminalsIP20
-
Design, Position, Mounting flange3
-
Depth, General60 mm
-
Length, General46 mm
-
Electrical data, Cable section, maximum2.5 mm², rigid
1.5 mm², flexible -
Electrical data, Cable section, minimum0.5 mm², rigid
0.5 mm², flexible -
Electrical data, Contact labellingX1 - X2
-
Type of electric connectionScrew terminals
-
Housing materialPlastic, glass-fibre reinforced thermoplastic, self-extingui
-
Voltage, rated operating voltage24 VDC
-
Type of application, Terminal designationEN 50005
EN 50013 -
Colour of the LEDRed
Blue
white -
Voltage, rated insulation voltage400 V
-
Voltage, Rated impulse withstand voltage4 kV
-
This product is unavailable
This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
-
Manufacturer Schmersal
-
