BCL 338i O M 100 D H F007 Stationary bar code reader

This stationary barcode reader features a special heating version and offers various functions such as AutoConfig, Alignment mode, AutoControl, and more. It has a typical scanning rate of 1,000 scans per second and a reading distance between 40 to 300 mm. The device uses an oscillating-mirror scanner as its reading method with a light beam exit at a side angle of less than 90 degrees. It operates on a supply voltage of 18 to 30 V DC and has selectable inputs/outputs. Interfaces include EtherCAT and USB 2.0, with a plug connector for connection. The device dimensions are 125 mm x 58 mm x 110 mm and it features an LED monochromatic graphic display with 128 x 32 pixels. Operational controls are button-based, and it can function in ambient temperatures ranging from -35 to 40 °C. The product is certified by c UL US.
