EX-RLDEWS24 EX command push button

EX-RLDEWS24
Screw connection
Mounting flange position 3
white LED
24 VAC/DC
  • SKU
    4030661601687
  • Manufacturer code
    101195062
  • Explosion protection parameters, category
    2G
    2D
  • Explosion protection parameters, designation
    D II 2G Ex ib IIC Gb
    D II 2D Ex ib IIIC Db
  • Explosion protection, regulations
    EN IEC 60079-0
    EN 60079-31
    EN 60079-14
    EN 60079-11
  • Explosion protection parameters, zones
    22
    2
    1
    21
  • Material, identification label
    Plastic, Polyamide PA
  • Standard, standards
    EN IEC 60947-5-1
    EN ISO 13849-1
    EN IEC 60947-5-5
    EN IEC 60204-1
    EN IEC 60947-5-3
    EN IEC 62061
    EN IEC 60947-1
  • PIM maintenance status
    Discharge "Online catalog"
  • PNV, standard, certificates
    IEC Ex
    TÜV
    cURus
  • Safety parameters, Mission time
    20 Year(s)
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4030661601687
  • SAP, product group
    Initial
  • SAP, gross weight
    12.000 g
  • SAP, net weight
    12.000 g
  • Temperature, ambient temperature, maximum
    55 °C
  • Web Type
    Product range
  • Type of application, Installation instructions
    pluggable
  • Type of application, Terminal designation
    EN 50005
    EN 50013
  • Colour of the LED
    white
  • Current, Thermal test current
    10 A
  • Current, Utilisation category AC-15
    6 A
  • Current, Utilisation category DC-13
    3 A
  • Type of Execution, Degree of pollution IEC/EN 60947-1
    3
  • Type of Execution, Terminals, mechanical
    arbitrarily
  • Type of Execution, IP Protection class, Switch rooms
    IP40
  • Type of Execution, IP Protection class, clips or terminals
    IP20
  • Type of Execution, Mechanical life, minimum,
    100000 Operations
  • Design, Position, Mounting flange
    3
  • Switching principle
    Slow action
  • Depth, General
    45 mm
  • Height, General
    25.5 mm
  • Length, General
    44 mm
  • Path, positive break travel
    2 mm
  • Width, General
    10 mm
  • Electrical data, Cable section, maximum
    2.5 mm²
    2.5 mm², rigid
    1.5 mm², flexible
  • Electrical data, Cable section, minimum
    0.5 mm², rigid
    0.5 mm², flexible
    2 x 1.0 mm², flexible
  • Electrical data, Max. fuse rating
    6 A gG D-fuse slow blow
  • Electrical data, Suitable for low-voltages
    ≥ 5 V / ≥ 1 mA
  • Electrical data, Utilisation category
    DC-13
    AC-15
  • Material, contacts, electrical
    Silver
  • Housing material
    Plastic, glass-fibre reinforced thermoplastic, self-extingui
  • Standard, climatic stress
    IEC 60068-2-30
  • Note, LED switching conditions display
    Supply voltage UB: 24 VAC/DC
  • Type of electric connection
    Screw terminals M20 x 1.5
  • Review, Resistance to vibrations to EN 60068-2-6
    5 g
  • Review, restistance to shock
    30 g / 18 ms
  • Temperature, Ambient temperature[generated product variant]
    -25 ... +55 °C
  • Temperature, ambient temperature, minimum
    -25 °C
  • Time, Switching frequency
    1200 /h
  • Tightening torque, tightening torque, screw
    1 Nm
  • Tightening torque, torque, clips
    1 Nm
  • Voltage, Rated impulse withstand voltage
    4 kV
  • Voltage, rated insulation voltage
    440 V
  • Voltage, Utilisation category AC-15
    250 VAC
  • Voltage, Utilisation category DC-13
    24 VDC
  • Selection (Yes/No), Integral System Diagnostics, general
    Yes
