Automatic reset function
2 safety contacts
Suitable for signal processing of emergency stop control devices, interlocking equipment, etc

SKU

4030661544939
Manufacturer code

103037577
Type of application, Terminal designation

IEC/EN 60947-1
Type of Execution, Degree of pollution IEC/EN 60664-1

2
Type of Execution, IP Protection class, Clearance

IP54
Type of Execution, IP Protection class, General

IP40
Type of Execution, IP Protection class, clips or terminals

IP20
Type of Execution, Mechanical life, minimum,

10000000 Operations
Type of execution, mounting

Snaps onto standard DIN rail to EN 60715
Type of Execution, Overvoltage category IEC/EN 60664-1

III
Depth, General

121 mm
Height, General

100 mm
Width, General

22.5 mm
Electrical data, Conduction resistance, maximum

30 Ω
Electrical data, Contact resistance, maximum

0.1 Ω
Material, contacts, electrical

AgSn0. self-cleaning, positive drive
Housing material

Glass-fibre reinforced thermoplastic, ventilated
Standard, climatic stress

EN 60068-2-78
Standard, EMC rating

EMC-Directive
Note, contact resistance

in new state
Note, General

Inductive loads (e.g. contactors, relays, etc.) are to be su
Note, Wiring diagram

The wiring diagram is shown with guard doors closed and in d
Monitoring 1 guard door(s), each with a magnetic safety sens
If only one external relay or contactor is used to switch th
To secure a guard door up to PL e and Category 4
The feedback circuit monitors the position of the contactors
Automatic start: The automatic start is programmed by conne
Number, LED's

5
Number, NC contacts

2
Number, Safety contacts

2
PIM maintenance status

Discharge "Online catalog"
Review, Resistance to vibrations to EN 60068-2-6

10 ... 55 Hz, Amplitude 0.35 mm
Review, restistance to shock

30 g / 11 ms
Safety parameters, Category, Stop 0

4
Safety parameters, Common Cause Failure (CCF), Relay outputs, minimum

65
Safety parameters Diagnostic Coverage (DC) Level, Stop 0

≥ 99 %
Safety parameters, Mission time, Relay outputs

15 Year(s)
Safety parameter

EN IEC 61508
EN ISO 13849-1
EN IEC 60947-5-1
Safety parameters, Performance Level, stop 0

e
Safety values, PFH value Stop 0

0.00000002 /h
Safety parameters, Safety Integrity Level (SIL), stop 0

3
Safety parameters, Stop-Category

0
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661544939
SAP, product group

Initial
SAP, gross weight

266.000 g
SAP, net weight

266.000 g
Temperature, Ambient temperature[generated product variant]

-25 ... +60 °C
Temperature, ambient temperature, maximum

60 °C
Temperature, ambient temperature, minimum

-25 °C
Temperature, storage and transport temperature,[generated product variant]

-40 ... +85 °C
Temperature, storage and transport temperature, maximum

85 °C
Temperature, storage and transport temperature, minimum

-40 °C
Time, Pull-in delay at automatic start, maximum, typically

300 ms
Tolerance, operating voltage, DC, maximum

20 %
Tolerance, operating voltage, DC, minimum

-10 %
Voltage, Rated control voltage at DC, maximum

28.8 VDC
Voltage, Rated control voltage at DC, minimum

20.4 VDC
Voltage, Rated impulse withstand voltage

4 kV
Voltage, rated operating voltage

24 VDC
Voltage, type

DC
Web Type

Product range
Selection (Yes/No), Earth connection detection

Yes
Selection (Yes/No), Integral System Diagnostics, status

Yes
Selection, (Yes/No), Wire breakage detection

Yes
Current, Consumption

57 mA
Current, Utilisation category AC-15

2 A
Current, Utilisation category DC-13

2 A
Electrical data, Utilisation category

DC-13
AC-15
Explosion protection parameters, category

3G
Explosion protection parameters, designation

D II (2) G [Ex ib Gb] IIC
D II (2) D [Ex ib Db] IIIC
D II 3 G Ex nA nC IIC T5 Gc (Ins
Explosion protection, regulations

EN IEC 60079-0
EN IEC 60079-15
EN 60079-11
Explosion protection parameters, zones

2
Note, applications

Safety sensor
Guard system
Emergency-Stop button
Pull-wire emergency stop switches
Time, Drop-out delay in case of "emergency stop", maximum

20 ms
Time, Drop-out delay in case of power failure, typically

20 ms
Time, Pull-in delay at RESET, typically

20 ms
Voltage, Utilisation category AC-15

230 VAC
Voltage, Utilisation category DC-13

24 VDC
Selection (Yes/No), Short-circuit recognition

Yes

Manufacturer Schmersal
Need our help?

or call us at

An inquiry about SRB200EXi-1A

Please enter your inquiry below and we'll get back to you as soon as possible.

Company

Your name

E-mail

Phone number

Message

Product attachments

file-28660-1948edc320ea1a5b5ae47a18ce9a8fa5.pdf (PDF, 614.05 kB)

Cart

SRB200EXi-1A EX machine safety relay module
